The PCF1252-Xs are low-power CMOS voltage threshold detectors designed especially for supervision of microcontroller/microprocessor systems for detection of power-on/off conditions and generation of a system reset pulse.
The Philips PCF1252-X family consists of low-power CMOS integrated circuits designed for supervising microcontroller and microprocessor systems. These devices detect voltage threshold conditions to generate system reset pulses and provide power-on/off status signals. The family offers ten versions with factory-programmed trip voltages ranging from 2.55 V to 4.75 V.
| Supply voltage range | 2.4 to 6.0 V |
|---|---|
| Operating temperature range | -40 to +85 °C |
| Typical supply current | 10 µA |
| Trip point accuracy | ±50 mV |
| Number of versions | 10 |
| COMIN switch point | 1.30 V |
The device operates within an ambient temperature range of -40 to +85 °C.
The device features very low current consumption, typically 10 µA.
