This is a quick start guide that introduces the features and specifications of the Delta 410 digital PCI audio card. This guide also covers hardware installation and Delta driver software installation (for PC).
The M-Audio Delta 410 is a 4-input, 10-output digital recording and playback interface designed for use with PC or Macintosh computers. It features two analog inputs, eight analog outputs, and coaxial S/PDIF I/O, supporting up to 24-bit data width and sampling rates from 8kHz to 96kHz.
The document covers hardware installation of the PCI host adapter card, software setup for Windows (95/98/NT/2000/ME) and Macintosh OS 8.5.1 or higher, and detailed usage of the included Delta Control Panel software. It also includes tutorials on recording workflows, troubleshooting tips, and technical specifications.
| Recording Interface | 4x10 24-bit/96khz full-duplex recording interface. |
|---|---|
| Analog I/O | 2x8 analog I/O, unbalanced on gold-plated RCA connectors. |
| Digital I/O | S/PDIF digital I/O on gold-plated RCA connectors. |
| Data Width | up to 24-bit data width and any sampling rate from 8kHz to 96kHz. |
| Dynamic Range D/A | 101.5 dB (A-weighted measured) |
| Dynamic Range A/D | 99.6 dB (A-weighted measured) |
| Total Harmonic Distortion | less than 0.002% at OdBFS |
| Frequency Response | 22-22kHz at 48kHz; 22-40kHz at 96kHz |
128 MB of PC100 RAM is required for 96kHz operation.
The device supports Windows 95, 98, NT, 2000 or ME, and Macintosh OS 8.5.1 or higher.
The analog I/O uses gold-plated RCA connectors.
