This document introduces the application of Agilent Fast Refinery Gas Analyzer. The instrument uses Flame Ionization Detector (FID) and Thermal Conductivity Detector (TCD) to detect C1 to C7 paraffins and olefins, as well as hydrogen, carbon dioxide, ethane, ethylene, acetylene, hydrogen sulfide, nitrogen, methane, and carbon monoxide. The instrument can also be customized for different analysis requirements.
The Agilent 583D-00 Fast Refinery Gas Analyzer provides rapid analysis with an approximate analysis time of 6 minutes. It utilizes a Flame Ionization Detector (FID) to detect C1 through C7 paraffins and olefins down to a detection limit of 20 ppm, and a Thermal Conductivity Detector (TCD) to detect hydrogen in a nitrogen carrier down to 100 ppm.
| Analysis Time | approximately 6 minutes |
|---|---|
| FID Detection Range | C1 through C7 paraffins and olefins |
| FID Detection Limit | 20 ppm |
| TCD Hydrogen Detection Limit | 100 ppm |
| TCD General Detection Limit | 200 ppm |
| TCD Carbon Monoxide Limit | 400 ppm |
| TCD Hydrogen Sulfide Limit | 500 ppm |
The analysis time is approximately 6 minutes.
The FID detects C1 through C7 paraffins and olefins.
The second TCD detects carbon dioxide, ethane, ethylene, acetylene, hydrogen sulfide, O2/Ar, nitrogen, methane, and carbon monoxide.
