The Yamaha PW2000M is a rack-mountable power supply specifically designed to provide regulated DC power for the M2000 series of mixing consoles. It comes in three models (100VAC, 120VAC, and 230VAC) intended for use with specific regional power supplies.
The manual details the front and rear panel features, including the power switch, operation monitor LEDs, umbilical connector pin assignments, and fuse replacement instructions. It also provides general specifications regarding dimensions, weight, output voltages, and mounting requirements.
| Dimensions (w x d x h) | 480 x 334.5 x 98 mm |
|---|---|
| Weight | 13kg |
| +17V Output Current | 2.5A |
| +12V Output Current | 3.8A |
| +48V Output Current | 0.34A |
It is specifically designed to provide power for the M2000 series of mixers.
A 6A 250V slow-blow fuse is required.
