The STB6100 is a highly integrated, low-cost, direct conversion (zero IF) tuner IC for DVB-S2 broadcast satellite applications. It includes an LNA, down-converting mixers, baseband low-pass filters, gain control, on-chip VCO and a low noise PLL.
The STB6100 is a highly integrated, low-cost direct conversion (zero IF) tuner IC designed for DVB-S2 broadcast satellite applications. Packaged in a small 32-pin QFN package, it includes an LNA, down-converting mixers, baseband low-pass filters, gain control, an on-chip VCO, and a low noise PLL. The device is controlled by a simple two-wire interface to minimize external components and simplify board layout.
| Input range | 950 to 2150 MHz |
|---|---|
| Symbol rate support | 1 to 45 Msymbol/s |
| Package type | QFN 32-pin |
The device supports an input range from 950 to 2150 MHz.
The tuner supports symbol rates from 1 to 45 Msymbol/s.
The device is controlled by a simple two wire interface.
