The STPC Client is an embedded microprocessor with powerful x86 processor, 64-bit 66MHz bus interface, 64-bit DRAM controller, SVGA graphics controller, UMA architecture, video scaler, video output port, video input port, and other features. It also includes PCI master/slave/arbiters, ISA master/slave, IDE controller, DMA controller, interrupt controller, timer/counters, and power management. The product integrates a standard 5th generation x86 core, a DRAM controller, a graphics subsystem, a video pipeline, and support logic including PCI, ISA, and IDE controllers to provide a single consumer-oriented PC compatible subsystem on a single device.
The STPC Client is a powerful x86 processor designed as a single PC-compatible subsystem on a single device. It integrates a standard 5th generation x86 core, a DRAM controller, a graphics subsystem, a video pipeline, and support logic including PCI, ISA, and IDE controllers. The device utilizes a Unified Memory Architecture (UMA) to share memory between the CPU and graphics/video frame buffers.
| Processor Core | Fully static 32-bit 5-stage pipeline |
|---|---|
| Clock Speed | Up to 75 MHz |
| Memory Support | Up to 4GB |
| System Memory | Up to 128 MBytes |
| DRAM Speeds | 60, 70, 80 & 100ns |
| Frame Buffer | Up to 4MB |
| RAMDAC | 135MHz |
| Display Resolution | 1024 x 768 x 75Hz |
| Package | PBGA388 |
It provides compatibility with DOS, Windows, and UNIX.
The device supports up to 128 MBytes of system memory.
Yes, it supports flash ROM.
