The KSZ8862-16MQL is a 2-port Ethernet switch that supports a non-PCI CPU interface and 10B-FL/100B-SX/100B-FX support, based on a proven, fourth-generation, integrated Layer 2 switch that is compliant with the IEEE 802.3u standard.
The Micrel KSZ8862-16MQL (or -32MQL) is the industry's first fully managed 2-port switch featuring a non-PCI CPU interface. It is designed for managed media converter applications, offering one port for fiber (10BASE-FL, 100BASE-SX/FX) and one for copper (10BASE-T, 100BASE-TX). The device integrates two MAC units, a high-speed non-blocking switch fabric, and a dedicated 1K entry forwarding table.
| Port 1 Support | 10BASE-FL / 100BASE-SX / 100BASE-FX |
|---|---|
| Port 2 Support | 10BASE-T / 100BASE-TX |
| Forwarding Table | 1K entry |
| Frame Buffer | On-chip |
| Power Supply | Single 3.3V |
| Package | 128-pin PQFP |
| Avg. Power Consumption | <400 mW |
Yes, it supports 802.1q VLAN for up to 16 groups.
The device operates on a single 3.3V supply.
