THS3001/02 is a high-performance high-speed current-feedback op amp from TI with a 420MHz bandwidth, 6500V/µs slew rate and 40ns settling time, making it ideal for communication, imaging and high-quality video applications.
The THS300x family consists of high-speed current-feedback operational amplifiers designed for communication, imaging, and high-quality video applications. Key features include a very fast slew rate of 6500 V/µs, a bandwidth of 420 MHz at unity gain, and an excellent settling time of 40 ns to 0.1%. The devices offer low distortion (THD = –96 dBc) and operate with supply voltages ranging from ±4.5 V to ±16 V.
| Slew Rate | 6500 V/µs |
|---|---|
| Settling Time (0.1%) | 40 ns |
| Total Harmonic Distortion (f = 1 MHz) | -96 dBc |
| Supply Voltage Range | ±4.5 V to ±16 V |
| Output Current (VCC = ±5 V, RL = 20 Ω) | 100 mA |
| Input Offset Voltage (Typical) | 3 mV |
The recommended operating conditions specify a split supply range of ±4.5 V to ±16 V.
The device offers a very low 3-mV maximum input offset voltage.
