The X28C010 is a 128K x 8 E2PROM fabricated with Xicor's proprietary, high performance, floating gate CMOS technology. It only requires 5V power and supports a 256-byte page write operation, with a write cycle of only 19µs/byte, allowing the entire memory to be written in less than 2.5 seconds.
The Xicor X28C010 is a 128K x 8 bit, 5 volt, byte alterable E2PROM fabricated with Xicor's proprietary high performance floating gate CMOS technology. It is a 5V only device compatible with industry standard EPROMs and features a JEDEC approved pinout for byte-wide memories.
The device supports a 256-byte page write operation, enabling the entire memory to be typically written in less than 2.5 seconds. Key features include simple byte and page write operations, self-timed programming without external high voltages, and early end of write detection via DATA Polling and Toggle Bit Polling. It also offers both hardware and software data protection options to safeguard nonvolatile data against inadvertent writes.
| Memory Capacity | 128K x 8 Bit |
|---|---|
| Supply Voltage | 5 Volt |
| Access Time | 120ns |
| Active Power | 50mA |
| Standby Power | 500uA |
| Endurance | 100,000 Write Cycles |
| Data Retention | 100 Years |
| Page Write Size | 256 bytes |
No, it does not require external high voltages or Vpp control circuits.
It provides both hardware features like noise protection and software data protection options.
The entire memory can typically be written in less than 2.5 seconds using page write.
