X76F128 is a security storage device from Xicor with 64-bit password security, programmable passwords, retry counter, 400kHz clock rate, 2-wire serial interface and many other features.
The X76F128 is a Secure SerialFlash memory device containing a 131072-bit array and a 512-bit array. Access to these memory arrays is controlled by two 64-bit passwords for read and write operations, with a separate password for resetting the device and clearing memory. The device features a proprietary Direct Write cell technology.
| Memory Capacity | 128K (16Kx8+64x8) |
|---|---|
| Clock Rate | 400kHz |
| Operating Voltage | 2.7 to 5.5V |
| Endurance | 100,000 Write Cycles |
| Data Retention | 100 years |
| Interface | 2 wire Serial Interface |
All parts are shipped from the factory with all passwords equal to '0'.
The retry counter allows 8 accesses with an invalid password before clearing memory arrays.
