International Rectifier SD400C Series Discrete Power Diodes Datasheet

SD400C is a standard recovery diode with a wide current range, high voltage ratings up to 2400V, and high surge current capabilities. It is suitable for various power converters, machine tool controls, high power drives and medium traction applications.

Brand: International Rectifier
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 7
File format: PDF
File size: 77 KB
Published: 11 June, 2012
Updated: 30 September, 2023
MD5 checksum: 4F682B149967F4A0B02B6FA3D1806FDF
PDF: International Rectifier SD400C Series Discrete Power Diodes Datasheet PDF

About this manual

This document is a data book for the International Rectifier SD400C..C Series of discrete power diodes. It provides detailed electrical specifications including voltage ratings ranging from 400V to 2400V and maximum average forward current capabilities up to 800A.

What's inside

Features
Typical Applications
Major Ratings and Characteristics
Electrical Specifications
Voltage Ratings
Forward Conduction Parameters
Thermal and Mechanical Specifications
Ordering Information

Specifications

Maximum average forward current	800 A (425 A)
Voltage range	400 to 2400 V
Case style	DO-200AA

Frequently asked questions

What are the typical applications for these diodes?

Typical applications include converters, power supplies, machine tool controls, high power drives, and medium traction applications.

What is the maximum non-repetitive surge current at 50Hz?

The maximum non-repetitive surge current is 8250 A.
