The ADC088S102 is a low-power, eight-channel CMOS 8-bit analog-to-digital converter from ADI. This device is based on a successive-approximation register architecture with an internal track-and-hold circuit and supports conversion rates of 500 kSPS to 1 MSPS. It can be configured to accept up to eight input signals and outputs serial data in straight binary format. The ADC088S102 supports independent analog and digital supplies, with a range of +2.7V to +5.25V for the analog supply (VA) and a range of +2.7V to VA for the digital supply (VD). In normal operation, the device consumes 1.8 mW and 8.0 mW of power with a +3V or +5V supply, respectively. The power-down feature reduces the power consumption to 0.03 µW and 0.15 µW with a +3V and +5V supply, respectively. The ADC088S102 is packaged in a 16-lead TSSOP package and is guaranteed to operate over an extended industrial temperature range of -40˚C to +105˚C.
The ADC088S102 is a low-power CMOS 8-bit analog-to-digital converter featuring eight input channels and a successive-approximation register architecture with an internal track-and-hold circuit. It supports conversion rates from 500 kSPS to 1 MSPS and offers compatibility with SPI, QSPI, MICROWIRE, and common DSP serial interfaces.
| Resolution | 8 Bits |
|---|---|
| Conversion Rate | 500 kSPS to 1 MSPS |
| Channels | Eight input channels |
| Package Type | 16-lead TSSOP |
The converter supports conversion throughput rates up to 1 MSPS.
Yes, the output serial data is compatible with several standards such as SPI.
The guaranteed performance range for the SCLK input is up to 16 MHz.
