The 74LV125 is a low-voltage silicon-gate CMOS device and is pin and function compatible with 74HC/HCT125. The 74LV125 consists of four non-inverting buffers/line drivers with 3-state outputs. The 3-state outputs (nY) are controlled by the output enable input (nOE). A HIGH at nOE causes the outputs to assume a high impedance OFF-state.
The Philips 74LV125 is a low-voltage Si-gate CMOS device consisting of four non-inverting buffers or line drivers with 3-state outputs. It is pin and function compatible with the 74HC/HCT125 series. The device features wide operating voltage ranging from 1.0 to 5.5 V, optimized for low voltage applications between 1.0 and 3.6 V.
| Operating voltage range | 1.0 to 5.5 V |
|---|---|
| Low voltage optimized range | 1.0 to 3.6 V |
| Number of buffers | Four non-inverting buffers/line drivers |
| Output type | 3-State |
| Operating temperature range | -40°C to +125°C |
The outputs are controlled by the output enable input (nOE). A HIGH at nOE causes the outputs to assume a high impedance OFF-state.
The device can be stored in a temperature range from -65°C to +150°C.
The 74LV125 consists of four non-inverting buffers/line drivers with 3-state outputs.
