The 74LV541 is a low-voltage CMOS device and is pin and function compatible with 74HC/HCT541. The 74LV541 is an octal non-inverting buffer/line driver with 3-state outputs. The 3-State outputs are controlled by the output enable inputs OE1 and OE2. A HIGH on OEn causes the outputs to assume a high impedance OFF state.
The Philips 74LV541 is an integrated circuit designed as a low-voltage CMOS device. It functions as an octal non-inverting buffer and line driver featuring three-state outputs controlled by enable inputs, making it suitable for bus driving applications.
This document provides comprehensive technical specifications including recommended operating conditions, absolute maximum ratings, DC characteristics, AC characteristics, and logic diagrams. It details the device's compatibility with 74HC/HCT541 parts and lists available package types such as DIL, SO, SSOP, and TSSOP.
| Supply Voltage Range | 1.0V to 3.6V |
|---|---|
| Number of Buffers | Octal (8) |
| Operating Temperature Range | -40°C to +125 °C |
| Input Capacitance (Typical) | 3.5 pF |
Yes, it is pin and function compatible with the 74HC/HCT541.
Outputs are controlled by OE1 and OE2 inputs; a HIGH on these inputs causes the output to enter a high impedance OFF-state.
