This document describes the features and characteristics of the PZM-NA series voltage regulator double diodes, including the maximum power dissipation per diode, small plastic package suitable for surface mounted design, and working voltage range.
The Philips PZM-NA series consists of low power general purpose voltage regulator double diodes designed for surface mounted design. These devices are housed in a small plastic SOT346 (SC59) package and are suitable for general regulation functions.
The document details the electrical characteristics for various working voltages ranging from 2.4V to 15V. It also specifies limiting values such as a maximum total power dissipation of 220 mW per diode and operating junction temperatures up to 150 °C.
| Total power dissipation | max. 220 mW per diode |
|---|---|
| Package type | SOT346 (SC59) |
| Operating junction temperature | -65 to +150 °C |
| Forward voltage (PZM2.4NBA) | 0.9 V at 10 mA |
| Working voltage range | 2.4 V and 15 V |
The maximum total power dissipation is 220 mW per diode.
The devices are available in a small plastic SOT346 (SC59) package.
They are intended for general regulation functions.
