HEF40098B is a 6-channel inverting buffer with 3 operating states, which are controlled by the EO4 and EO2 enable pins.
The HEF40098B is an integrated circuit designed as a hex inverting buffer featuring three-state outputs. The output states are managed by two enable inputs (EO1 and EO2), where a HIGH signal on either input causes the respective buffer elements to enter a high impedance or OFF state.
| Product Type | Hex inverting buffer with 3-state outputs |
|---|---|
| Enable Inputs | Two enable inputs (EO1 and EO2) |
| Package Types | 16-lead DIL plastic, ceramic, or SO |
A HIGH signal on one enable input causes four of the six buffers to go into a high impedance state, while a HIGH on the other enables the remaining two.
The 16-lead DIL plastic package contains sixteen pins.
