This document is the service handbook for Agilent 1049A Electrochemical Detector, describing installation, performance verification, and test features. The handbook includes information about hardware, cables and connectors, and a parts reference list.
The Agilent 1049A Electrochemical Detector Service Handbook serves as a technical guide for maintenance and repair. It details the internal components of the instrument, including the Main Power Supply, Keyboard and Display Module, Controller Board, Preamplifier Board, and Flow Temperature Controller Board.
Additionally, the document covers external connections by describing various connectors and cables used with the detector, such as those for the Integrator, Auxiliary Output, and Remote interfaces. It concludes with an illustrated parts breakdown and specific sections for miscellaneous components.
| Switching Frequency | 50 kHz |
|---|---|
| Line Voltage (100-120V) | 1 A slow fuse |
A 1 A slow fuse with part number 2110-0007 is required.
A 0.5 A slow fuse with part number 2110-0202 is required.
The Main Power Supply works with a switching frequency of 50 kHz.
