The PEEL18CV8 is a Programmable Electrically Erasable Logic (PEEL) device providing an attractive alternative to ordinary PLDs.
The PEEL 18CV8 is a CMOS Programmable Electrically Erasable Logic Device designed to provide an alternative to ordinary PLDs. It features superior factory testing and the ability to be reprogrammed in plastic packages, which reduces retrofit and development costs.
Available in Commercial and Industrial versions with speeds ranging from 5ns to 25ns, the device is offered in 20-pin DIP, PLCC, SOIC, and TSSOP packages. It supports third-party software and programmers as well as ICT's proprietary PLACE development software.
| Supply Voltage (Vcc) | 5 Volts +10% |
|---|---|
| Operating Speeds | 5ns to 25 ns |
| Power Consumption (Max) | 37mA at 25MHz |
| Input Pins | 10 inputs |
| I/O Pins | 8 I/O pins |
| Product Terms | 74 product terms |
The device is available with speeds ranging from 5ns to 25 ns.
Yes, it is a CMOS Electrically Erasable Technology device that can be reprogrammed in plastic packages.
ICT offers free PLACE development software and a low-cost PDS-3 programmer system.
