The document introduces the PDIUSBD11 USB device with a serial interface. It complies with the Universal Serial Bus specification Rev. 1.1, ACPI, OnNOW, and USB power management requirements. It is also compliant with USB Human Interface Devices and Monitor Control Class. The PDIUSBD11 integrates a Serial Interface Engine, FIFO memory, and transceivers, and has automatic USB protocol handling. It has a high-speed I2C interface (up to 1 Mbit/s) and is compatible with the PDIUSBH11 software. Additionally, it features a low-frequency 12 MHz crystal oscillator, programmable output clock frequency, bus powered capability with low suspend current, and a single 3.3 V supply with 5 V tolerant I/O. It is available in 16-pin DIP and SO packages.
The Philips PDIUSBD11 is a Universal Serial Bus (USB) device with a serial interface designed for microcontroller-based systems. It acts as a cost and feature-optimized USB peripheral that communicates with the system microcontroller over a high-speed I2C bus.
This integrated solution includes an on-chip Serial Interface Engine (SIE), FIFO memory, and transceivers to handle full USB protocol layers without firmware intervention. Key features include SoftConnect technology for software-controlled connection to the USB bus, support for ACPI power management, and compatibility with the PDIUSBH11 software family.
| USB Specification Compliance | Universal Serial Bus specification Rev. 1.1 |
|---|---|
| I2C Interface Speed | Up to 1 Mbit/s |
| Crystal Oscillator Frequency | 12 MHz |
| Supply Voltage | 3.3 V |
| Operating Temperature Range | -40°C to +85°C |
| Available Packages | 16-pin DIP and SO |
The device complies with the Universal Serial Bus specification Rev. 1.1.
No, the device implements the full USB protocol layer completely hardwired and needs no firmware intervention.
The I2C interface can support clock speeds up to 1 MHz.
