About this manual

This document is a technical datasheet for the Microsemi AD Series of 1.6 Amp Silicon Controlled Rectifiers (SCRs). The series includes models AD100 through AD118, designed for medium-current control and sensing applications with blocking voltages ranging from 60 to 400 volts.

What's inside

Features
Absolute Maximum Ratings
Mechanical Specifications
Electrical Specifications
Gate Trigger Current vs Temperature
Holding Current Characteristics

Specifications

Maximum Gate trigger Current (AD107)	20 uA
Maximum Gate trigger Current (AD114)	200 uA
Voltage Ratings Range	60 to 400 volts
Gate Trigger Voltage (Typical)	.52 V

Frequently asked questions

What is the maximum gate trigger current for the AD107 series?

The maximum gate trigger current (Iq) for the AD107 series is 20 uA.

What are the Microsemi AD Series SCRs designed for?

They are designed for medium-current control and sensing applications.

What is the maximum gate trigger current for the AD100 series?

The AD100 series offers a maximum gate trigger current of 2.0 microamps.

What is the typical range for the gate trigger voltage?

The tight gate trigger voltage range is from .44 to .6V.
