TDA8350Q is a power circuit for use in 90° and 110° colour deflection systems for field frequencies of 50 to 120 Hz. The circuit provides a DC driven vertical deflection output circuit, operating as a highly efficient class G system and an East-West driver for sinking the diode modulator current.
The Philips TDA8350Q is an integrated circuit designed as a power circuit for use in 90° and 110° colour deflection systems operating at field frequencies of 50 to 120 Hz. It functions as a highly efficient class G system providing a DC-driven vertical deflection output circuit.
| Supply Voltage (Vp) | 9 - 25 V |
|---|---|
| Quiescent Current (Ip) | 30 mA |
| Vertical Output Current | 3 A peak-to-peak |
| Flyback Supply Voltage (Veg) | 50 V |
| East-West Sink Output Current | 500 mA |
| Operating Ambient Temperature | -25 to +75 °C |
The circuit is for use in colour deflection systems for field frequencies of 50 to 120 Hz.
Yes, it can be used with the TDA9150, TDA9151B, TDA9160A, TDA9162, TDA8366 and TDA8367.
A flyback supply voltage of up to 60 V is allowed in application.
