Motorola MC92308 OFDM Demodulator Datasheet

This document introduces the features and characteristics of MOTOROLA MC92308 OFDM demodulator

Brand: Motorola
Category: Other Electronics
Document type: Datasheet
Language: English
Pages: 4
File format: PDF
File size: 27 KB
Published: 06 June, 2012
Updated: 30 September, 2023
MD5 checksum: BFA478BE86E5C218F78C50DD9EF60DED
PDF: Motorola MC92308 OFDM Demodulator Datasheet PDF

About this manual

The Motorola MC92308 is an Orthogonal Frequency Division Multiplex (OFDM) Demodulator designed for 2K transmission modes according to the ETSI specification for digital terrestrial broadcasting. It contains all functionality required to demodulate information transmitted in one UHF channel, supporting various modulation schemes and guard interval lengths.

What's inside

Feature Summary
Ordering Information
Pin Description
Package
Companion Product
Warranty Disclaimer

Frequently asked questions

What is the MC92308?

The MC92308 is an Orthogonal Frequency Division Multiplex Demodulator for 2K transmission mode according to the ETSI specification.

What channels is the device usable for?

The device is usable for 8MHz, 7MHz, and 6MHz channels by adjusting the clock rate.

What modulation types does it support?

The device supports QPSK, 16-QAM, and 64-QAM.
