The X02 series is a high-sensitivity 1.25A SCR produced by Schneider Electric. It is suitable for all applications where the available gate current is limited, such as ground fault circuit interruptors, overvoltage crowbar protection in low power supplies, capacitive ignition circuits, etc. These devices are optimized in forward voltage drop and inrush current capabilities, for reduced power losses and high reliability in harsh environments.
The X02 Series consists of highly sensitive 1.25A SCRs designed for applications where gate current is limited, such as ground fault circuit interruptors and overvoltage crowbar protection. These devices are optimized for low forward voltage drop and high inrush current capabilities to ensure reliability in harsh environments.
| Forward Voltage Drop (Vf) | 600 and 800 V |
|---|---|
| Leakage Current (Ileak) | 50 to 200 pA |
| Maximum Average On-State Current (Ioav) | 1.25 A |
| Operating Junction Temperature Range (Tj) | -40 to +125 °C |
| Storage Junction Temperature Range (Tstg) | -40 to +150 °C |
| Junction to Leads Thermal Resistance (TO-92) | 60 °C/W |
The series is available in 600 V and 800 V variants.
The devices are available in through-hole (TO-92) or surface-mount (SOT-223) packages.
The maximum average gate power dissipation at Tj = 125°C is 0.2 W.
