M27V401 is a low voltage 4 Mbit EPROM offered in UV and OTP erase modes. It is ideally suited for microprocessor systems requiring large data or program storage and is organized as 524,288 x 8 bits. The M27V401 operates in the read mode with a supply voltage as low as 3V. The decrease in operating power allows either a reduction of the size of the battery or an increase in the time between battery recharges.
The M27V401 is a 4 Mbit (612Kb x8) Low Voltage UV EPROM and OTP EPROM offered by STMicroelectronics. It is organized as 524,288 by 8 bits and operates in read mode with a supply voltage as low as 3V.
| Capacity | 4 Mbit (612Kb x8) |
|---|---|
| Organization | 524,288 by 8 bits |
| Read Supply Voltage | 3V to 3.6V |
| Access Time (Standard) | 120ns |
| Active Current | 15mA at 5MHz |
| Standby Current (CMOS) | 20uA |
| Programming Voltage | 12.75V + 0.25V |
| Programming Time | 100us/byte (typical) |
The manufacturer code for this device is 20h.
The device code is 41h.
Yes, if it is the UV range version, a new pattern can be written after exposing the chip to ultraviolet light.
