Update: 28 September, 2023
The M series power entry modules offer the most choices of power entry components and filtering options to fit a specific need. The fully configured M series expands the options of a manufacturer whose products are marketed worldwide. One component, fully assembled and tested, provides the capability of interfacing a multi-voltage power supply to any common voltage or fusing scheme in the world, without modification. The IEC connector provides an internationally accepted power entry termination, which can be used with a variety of line cords. The selectable fuseholder allows use of single or dual European fuses, or a single North American fuse. The optional DPST on/off switch breaks both sides of the line and is labeled with the international I/O markings. The optional voltage selector provides a convenient means to change transformer primary connection, and it is available in both 2-voltage and 4-voltage configurations. The series is available with four filter circuits to meet a variety of applications, and convenient connections are provided on unfiltered models to allow wiring of a separate RFI filter. The M series is a family of components offering maximum flexibility and cost-effectiveness in the selection of primary power components. Wiring to the modules is accomplished via .110” terminals for labor savings and convenience. Four filter circuits provide a choice of attenuation tailored to specific categories o
File format: PDF
Size: -
MD5 Checksum: 2C428221D3CCD1F5DFF883E55D7EAAB5
Publication date: 05 June, 2012
Downloads: -
PDF Link: CORCOM M SERIES Datasheet PDF
