The G923 is a low supply current, high PSRR, and low dropout linear regulator that comes in a space saving SOT-23-5 package.
The G923 is a low supply current, high PSRR, and low dropout linear regulator designed for battery-powered applications such as notebook computers, cellular phones, and PDAs. It features a guaranteed 300mA output current with a maximum no-load supply current of 90uA.
| Maximum Output Current | 300 mA |
|---|---|
| No-Load Supply Current | 90uA |
| Dropout Voltage (150mA) | 200mV |
| PSRR at 120Hz | 65dB |
| Operating Voltage Range | 2.5V to 5.5V |
| Package Type | SOT-23-5 |
The maximum supply current in shutdown mode is less than 1pA.
Yes, it is stable with low cost ceramic capacitors.
