The 2801550 LGA775 Pentium 4 Intel 865G Industrial Motherboard is based on the Intel® 865G chipset and supports 533/800MHz processor FSB for processor speeds of up to 3.8GHz. The motherboard has two DDR memory sockets on board, and supports up to 2GB DDR memory.
The Award 2801550 is an ATX‑form factor industrial motherboard based on the Intel® 865G chipset. It supports LGA775 Intel Pentium 4 and Celeron D processors up to 3.8 GHz, up to 2 GB of DDR memory, and provides multiple I/O options including Ethernet, USB 2.0, SATA, and a CompactFlash socket.
The manual covers hardware installation, jumper settings, BIOS configuration, driver installation, and includes an appendix with I/O port maps and IRQ assignments. Contact information for Global American Inc. is provided at the end of the document.
| CPU Socket | LGA775 (Intel Pentium 4 / Celeron D) |
|---|---|
| Supported CPU Speed | 2.53 GHz ~ 3.8 GHz |
| Chipset | Intel 865G / 865GV |
| Memory | 2 × DDR400/333/266 SDRAM, max 2 GB |
| USB Ports | 6 × USB 2.0 |
| Board Size | 305 mm × 244 mm (12" × 9.5") |
| Watchdog Timer | Yes, 256‑segment timer |
It supports LGA775 Intel Pentium 4 and Celeron D processors up to 3.8 GHz.
The board provides six USB 2.0 ports.
The motherboard measures 305 mm by 244 mm (approximately 12 in × 9.5 in).
Yes, it includes a watchdog timer with 256 segments.
