This PDF file introduces Global's temperature measurement solutions, including connectors, cables, sensors, calibration blocks and instrumentation.
Global Measurement and Control designs and manufactures temperature measurement solutions, including a full range of miniature and standard thermocouple connectors. The catalog lists each connector type, its part number, and available accessories.
Connectors are offered with maximum temperature ratings of 220 °C and 560 °C, colour‑coded to IEC 584.3:1989 for the 220 °C version. Miniature in‑line connectors use a 3 mm cable entry, while standard in‑line connectors use a 6 mm entry, and pins are polarised by size and marked for polarity.
| Maximum temperature rating | 220 °C and 560 °C |
|---|---|
| Cable entry size (miniature) | 3 mm |
| Cable entry size (standard) | 6 mm |
| Colour coding standard (220 °C) | IEC 584.3:1989 |
The connectors are rated for either 220 °C or 560 °C.
Miniature in‑line connectors have a 3 mm cable entry.
They follow the IEC 584.3:1989 international colour standard.
Pins are polarised by size and marked for negative and positive polarity.
