The EC28 series is an oscillator produced by ECLIPTEK CORP. The series uses HCMOS output, 2.5V supply voltage, 14-pin DIP package, and stability up to ±20ppm. Custom lead length and gull wing options are available.
This document provides a technical overview of the ECLIPTEK EC28 series oscillators. It details key features such as RoHS compliance, HCMOS output logic, and a supply voltage of 2.5V. The datasheet covers both 14-pin DIP and 8-pin DIP package variants.
| Frequency Range | 1.544MHz to 33.000MHz |
|---|---|
| Supply Voltage | 2.5V +/- 5% |
| Storage Temperature Range | -55°C to 125°C |
| Load Drive Capability | 15pF HCMOS Load |
The frequency tolerance/stability options include +100ppm, +50ppm, +25ppm, or +20ppm maximum.
Yes, the document states that the product is RoHS Compliant (Pb-free).
