This document is a bulletin from Ecliptek Corporation notifying all customers that the following series of products will be terminated effective May 10, 2004: EB51F2 5V 14 Pin DIP TCXO, HCMOS, ES51F2 5V 14 Pin DIP TCXO, Sinewave, EB52F2 3.3V 14 Pin DIP TCXO, HCMOS, ES52F2 3.3V 14 Pin DIP TCXO, Sinewave. Ecliptek Corporation will not provide an end-of-life policy for these products, but will provide a recommended alternative product within 90 days.
This marketing bulletin notifies customers that the EB51F2, ES51F2, EB52F2, and ES52F2 temperature‑compensated crystal oscillator (TCXO) series are being discontinued as of May 10 2004. No end‑of‑life policy will be applied and there is no immediate replacement, though a recommended alternative will be offered within 90 days.
The document also provides the standard specifications for the affected parts, including frequency range, supply voltage, input current, phase noise, and environmental test requirements. These technical details remain useful for design reference even after the product line is terminated.
| Frequency Range | 1.544 MHz to 44.736 MHz |
|---|---|
| Supply Voltage (Vdd) | 5.0 V dc + 5 % |
| Input Current (Steady State @25 °C) | 15 mA Maximum < 20 MHz |
| Phase Noise (Typical) | -60 dBc/Hz at 10 Hz offset |
| Operating Temperature Range | -55 °C to +125 °C |
The termination is effective May 10 2004.
No, there will be no end‑of‑life policy exercised for these series.
