The document is about the termination of the Ecliptek EC20 series products. The series will be discontinued on March 31, 2007 and delivery will end on June 30, 2007.
This marketing bulletin notifies customers that the Ecliptek EC20 3.3 V 14‑pin DIP oscillator will be discontinued effective December 27th, 2006. New orders will not be accepted after March 31st, 2007, and all deliveries must be completed by June 30th, 2007.
The bulletin also provides key electrical specifications for the EC20 series and lists the recommended replacement parts (EB52F3 or EB52F5). Technical data such as frequency range, supply voltage, temperature limits, and output logic levels are included for reference.
| Frequency Range | 1.000 MHz to 50.000 MHz |
|---|---|
| Supply Voltage | 3.3 V DC ±10% |
| Operating Temperature Range | -55 °C to 125 °C |
| Output Logic High (VOH) | ≥2.7 V DC |
| Output Logic Low (VOL) | ≤0.5 V DC |
| Frequency Stability | ±5 ppm |
The EC20 oscillator is discontinued effective December 27th, 2006.
New orders will not be accepted after March 31st, 2007.
All deliveries must be concluded by June 30th, 2007.
