This document is the datasheet of AVX's multilayer ceramic chip capacitor, which mainly introduces the characteristics and features of the product.
The document outlines basic capacitor formulas and explains how to order parts using the specific AVX part number system. It details specifications for four main dielectric types: C0G (NP0), X7R, Z5U, and Y5V, including their capacitance ranges, tolerances, and operating temperature characteristics.
Additionally, the text covers environmental and mechanical general specifications, military and European version part number identification, packaging configurations such as automatic insertion and bulk cases, and a surface mounting guide.
| C0G (NP0) Capacitance Change with Temperature | 0 ±30ppm/°C |
|---|---|
| C0G (NP0) Operating Temperature Range | -55°C to +125°C |
| C0G (NP0) Dielectric Strength | 250% of rated voltage for 5 seconds |
The capacitance range is from 0.5 pF to .1 µF.
The preferred tolerances are ±5% and ±10%, with others available.
The minimum insulation resistance is 100,000 megohms or 1000 M Ω- µF min.
