This document provides information on the performance characteristics, outline dimensions, ordering information, marking and packaging of KEMET Electronics Corporation's products. It also includes the part number ratings for different series of products.
The KEMET wet tantalum capacitor family includes commercial (T19X) and military (T29X) series such as T190/T290, T191/T291, T192/T292, T195/T295, T197 and T198. The document provides performance characteristics, dimensional drawings, ordering details, marking, and packaging information for each series.
Key features covered are temperature range, rated voltage, capacitance measurement method, dissipation factor, ESR behavior, leakage current trends, and reliability data. The catalog also includes important notices, test procedures, and environmental considerations for reliable use in blocking, decoupling, filtering, and timing applications.
| Storage Temperature Range | -55 °C to +125 °C |
|---|---|
| Capacitance Measurement Conditions | 120 Hz, 25 °C, up to 1 V rms applied |
| Dissipation Factor (DF) Measurement Conditions | 120 Hz, 25 °C, up to 1 V rms applied |
They can be stored from –55 °C up to +125 °C without applied voltage.
