The T494 series offers low ESR values in EIA 535BAAC sizes, capacitance from 0.1 µF to 1000 µF, and voltage ratings of 3‑50 VDC. Features include optional gold‑plated terminations, laser‑marked cases, and new low‑profile case sizes, with 100% surge‑current testing on selected sizes.
Ordering information provides part numbers that encode capacitance, voltage, tolerance and termination options. Detailed mechanical drawings give case dimensions for each size, and the construction section describes the molded polarity, silver‑adhesive cathode and standard solder coating (90 Sn/10 Pb).
| Capacitance range | 0.1 µF to 1000 µF |
|---|---|
| Voltage rating | 3‑50 VDC |
| Tolerance | +10% or +20% |
| ESR characteristic | Low ESR values in EIA 535BAAC sizes |
| Lead material (solder coating) | 90 Sn/10 Pb (standard) |
The T494 series is rated for 3 V to 50 VDC.
Capacitance values range from 0.1 µF up to 1000 µF.
Yes, optional gold‑plated terminations are available.
The series offers +10% or +20% tolerance options.
