This document is the user manual for AXIS 240Q Video Server, applicable for firmware release 4.40. It includes instructions for using and managing the AXIS 240Q on your network. Previous experience of networking will be of use when installing and using this product. Some knowledge of UNIX or Linux-based systems would also be beneficial, for developing shell scripts and applications.
The Axis 2400 Video Server is a network‑connected video server designed for security surveillance and remote monitoring. It captures up to four analog video sources, encodes them as Motion JPEG streams, and makes them available over Ethernet.
This User Manual explains installation, network configuration, front‑ and rear‑panel connections, PTZ integration, system options, and troubleshooting. It also includes specifications, battery replacement instructions, and references to online help and firmware updates.
| Battery type | 3.0V CR2032 Lithium |
|---|---|
| Battery life | Minimum 5 years |
| Video inputs | Up to 4 analog sources |
| Maximum frame rate | 5 fps (PAL) / 6 fps (NTSC) |
| Supported resolutions | Up to 4CIF (5 resolutions) |
| Maximum simultaneous viewers | 20 |
| Serial ports | RS‑232 and RS‑485 |
| Alarm I/O | 4 alarm inputs, 4 alarm outputs |
| Web server | Built‑in HTTP/HTTPS interface |
| Network speed detection | 10BaseT / 100BaseTX |
It uses a 3.0 V CR2032 Lithium battery.
Under normal conditions the battery lasts for a minimum of five years.
The server can digitize up to four analog video sources.
Up to twenty viewers can access the video server at the same time.
