This document includes instructions for installing the AXIS Q7424-R on your network. Previous experience of networking will be beneficial when installing the product. Video and audio surveillance can be prohibited by laws that vary from country to country. Check the laws in your local region before using this product for surveillance purposes. This product includes one (1) H.264 decoder license and one (1) AAC license. To purchase further licenses, contact your reseller. This equipment has been designed and tested to fulfill applicable standards for radio frequency emission and immunity to electrical and electromagnetic phenomena. In the USA, using shielded cables (STP) may be appropriate depending on the electrical environment. The equipment has been tested using shielded cables (STP) and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. For more information, refer to the user manual.
This Installation Guide provides detailed instructions for mounting the Axis 07424‑R video encoder, connecting power, network and optional I/O devices, and configuring its IP address. It also includes safety, legal and environmental considerations for indoor and outdoor installations.
Key sections cover hardware overview, mounting procedures, power options (AC, DC, PoE), network setup using DHCP or static IP, and battery replacement information for the internal RTC.
| Dimensions | 45 mm × 135 mm × 167 mm (HxWxD) |
|---|---|
| Weight | 0.8 kg (1.7 lb) |
| Battery type | 3.0 V CR2032 Lithium battery |
| Power options | AC power, DC power input, or PoE |
| Network interfaces | RJ45 (PoE) and optional 1 Gbps SFP module (SFP priority higher) |
The encoder will use 192.168.0.90 as the default IP address.
No, the casing is not approved for outdoor use; an approved outdoor housing is required.
The battery is expected to last a minimum of five years.
It complies with EN/IEC 60950‑1 and EN/IEC/UL 60950‑1 for safety of IT equipment.
