This is a user manual for the Leica TPS700 series
The TPS700 Series is an electronic total station designed for construction and cadastral surveying. It features a laser plummet, reflectorless EDM, and automatic target recognition to improve efficiency on the field.
This manual covers safety symbols, product identification, battery handling, tripod setup, laser plummet use, measuring procedures, care and storage, and detailed technical specifications such as angle accuracy, telescope magnification, and power requirements.
| Angle measurement type | Type 702 – 2" (0.6 mgon) |
|---|---|
| Telescope magnification | 30x |
| Laser plummet accuracy | max deviation 1.5 mm (2 σ) at 1.5 m height |
| Battery voltage | 6 V |
| Instrument weight (TC/TCR) | 4.6 kg |
| Instrument height with tribrach GDF111 | 360 mm ± 5 mm |
The laser plummet has a maximum deviation of 1.5 mm (2 σ) at an instrument height of 1.5 m.
