The Leica GS09 Quick Guide provides an overview of the hardware setup and real-time reference setup steps for the product, and introduces the features of the CS09 field controller.
This guide introduces the Leica GS09 total station and its accessories, including the GNSS antenna, battery, CompactFlash card, and tripod bracket. It explains how to configure the device for real‑time rover operation, navigate the screen display and main menu, and manage data.
Detailed procedures cover data transfer to a PC via the CS09 field controller, importing DXF/ASCII/GSI files into jobs, setting up the GS09 as a real‑time reference station, and performing GPS resection for coordinate calibration.
