The TS68EN360 QUad Integrated Communication Controller (QUICC) is a versatile one-chip integrated microprocessor and peripheral combination that can be used in a variety of controller applications. It particularly excels in communications activities. The QUICC can be described as a next-generation TS68302 with higher performance.
The TS68EN360 QUAD Integrated Communication Controller (QUICC) is a 32‑bit microprocessor with four serial communication controllers, designed for a wide range of controller applications. The document lists its core features, such as a CPU32+ processor delivering 4.5 MIPS at 25 MHz, up to 32‑bit data bus, and extensive peripheral options.
Detailed sections cover the device architecture, pin‑out diagrams for the 241‑lead PGA package, signal groups, and a comprehensive system‑bus signal index. The handbook also includes quality compliance information and Atmel corporate contact details.
| Processor | CPU32+ (4.5 MIPS at 25 MHz) |
|---|---|
| Data Bus Width | Up to 32‑bit (dynamic sizing for 8 and 16 bits) |
| Address Lines | Up to 32 (at least 28 always available) |
| Temperature Range | -55 °C to +125 °C (military) |
| Power Consumption (25 MHz) | 1.4 W at 5.25 V |
| Power Consumption (33 MHz) | 2 W at 5.25 V |
The TS68EN360 uses a CPU32+ core that runs at 4.5 MIPS when clocked at 25 MHz.
It is qualified for military temperature range from –55 °C up to +125 °C.
The controller provides up to 32 address lines, with at least 28 always available.
The device consumes about 1.4 W when operating at 25 MHz and 5.25 V.
