The AMS1084 series of adjustable and fixed voltage regulators are designed to provide 5A output current and to operate down to 1V input-to-output differential.
The AMS1084 family provides adjustable and fixed low‑dropout voltage regulation with a maximum output current of 5 A and dropout voltage guaranteed at 1.5 V at full load. Features include 0.015 % line regulation, 0.1 % load regulation, and a 1.25 V reference voltage. The devices are offered in TO‑220 and TO‑263 (plastic DD) packages and operate from –40 °C to 125 °C.
These regulators are suited for high‑efficiency linear regulation, post‑regulation of switching supplies, microprocessor power, battery chargers, and portable instrumentation. They are pin‑compatible with older three‑terminal regulators and include internal short‑circuit protection and thermal shutdown.
| Maximum Output Current | 5 A |
|---|---|
| Line Regulation | 0.015 % |
| Load Regulation | 0.1 % |
| Operating Junction Temperature Range | 0 °C to 125 °C |
| Package Types | TO‑220, TO‑263 |
The device can deliver up to 5 A of output current.
The regulator is offered in both TO‑220 and TO‑263 (plastic DD) packages.
Line regulation is specified as 0.015 %.
