TD352 is an advanced gate driver for IGBT and power MOSFET from ON Semiconductor, with features such as 1A sink / 0.75A source min. gate drive, active Miller clamp feature, desaturation detection, adjustable and accurate turn-on delay, UVLO protection and 2kV ESD protection.
The TD352 is an advanced gate driver for IGBT and power MOSFET devices, offering integrated control and protection functions such as active Miller clamp, desaturation detection, UVLO and ESD protection. It supports high‑reliability designs and includes programmable turn‑on delay and adjustable dead‑time.
The datasheet lists absolute maximum ratings, detailed electrical characteristics, timing diagrams, and mechanical dimensions for both DIP‑8 and SO‑8 packages. It also provides pin‑out information, recommended external components, and revision history.
| Maximum Supply Voltage (VH‑VL) | 28 V |
|---|---|
| Power Dissipation | 500 mW |
| Operating Temperature Range | -40 to 125 °C |
| ESD Protection | 2 kV |
| Output Sink Current | 1.0‑1.7 A |
| UVLO Top Threshold | 10‑12 V |
