The ACS755xCB-100 is a Hall current sensor produced by Texas Instruments. It uses a single +5V supply and can measure AC and DC currents. It features high reliability, extremely low power consumption, 27kHz bandwidth, 3kVRMS isolation voltage and other characteristics.
The ACS755xCB-100 is a monolithic Hall‑effect current sensor from Allegro MicroSystems. It offers a single‑supply +5 V operation, 3 kV isolation between the primary terminals and the sensor pins, and a compact CB‑PSF/CB‑PFF package for easy mounting. The device is calibrated at the factory and designed for automotive, industrial, power‑conversion and battery‑monitoring applications.
The datasheet lists electrical characteristics such as supply voltage, current range, bandwidth, and isolation voltage, as well as dynamic response parameters like propagation delay, response time and rise time. Mechanical details, safety standards, and package dimensions are also provided for designers.
| Supply Voltage (Vcc) | 5.0 V typ (5.5 V max) |
|---|---|
| Primary Sensed Current (Ip) | 0 – 100 A |
| Bandwidth (‑3 dB) | 27 kHz |
| Package Mass | 4.63 g typical |
It operates from a single +5 V supply (typical 5.0 V, max 5.5 V).
The -3 dB bandwidth is 27 kHz.
