The UDN2993B and UDN2993LB are dual full-bridge motion control ICs that provide cost-effective, monolithic drive electronics for bipolar stepper and dc (brush) servo motors to 30 V and 500 mA.
The document describes the UDN2993B and UDN2993LB, which are cost-effective monolithic drive electronics for bipolar stepper and brush servo motors operating up to 30V. These dual full-bridge motion control ICs integrate separate inputs, level shifting, control logic, inductive transient protection, and source/sink drivers in an H-bridge configuration.
| Output Current | +600 mA |
|---|---|
| Load Supply Voltage | 30 V |
| Logic Supply Voltage | 7.0 V |
These devices are designed for bipolar stepper and brush servo motors.
Yes, excepting the power supply connections, the two H-bridges are independent.
The maximum output voltage to the load is 30 V.
