ADV7622 is a 4-input, 1-output multiplexed HDMI transceiver that supports HDMI 1.4a standard. It features audio return channel, 3D TV support, content type bits, CEC 1.4 compatibility, extended colorimetry, High-Bandwidth Digital Content Protection (HDCP 1.4), HDCP repeater support, etc.
The ADV7622 is a high‑performance HDMI transceiver that integrates HDMI 1.4 receiver and transmitter functions with digital audio I/Os on a single chip. It provides four HDMI Rx inputs, one HDMI Tx output, and supports HDMI 1.4a, HDCP 1.4, ARC, CEC 1.4, and deep‑color video formats up to 36‑bit.
Typical applications include AVRs, sound bars with HDMI repeater support, HBR‑enabled TVs and other repeater‑based systems. The device is supplied in a 144‑lead, 20 mm × 20 mm Pb‑free LQFP package and operates from 0 °C to +70 °C.
| HDMI inputs | 4 HDMI Rx inputs |
|---|---|
| HDMI output | 1 HDMI Tx output |
| HDMI version | HDMI 1.4a |
| Deep Color | 36‑/30‑/24‑bit |
| Maximum video resolution | 1600 × 1200 @ 60 Hz |
| Package | 144‑lead 20 mm × 20 mm Pb‑free LQFP |
| Operating temperature | 0 °C to +70 °C |
| HDCP support | HDCP 1.4 repeater |
It supports HDMI 1.4a.
Yes, the chip provides an audio return channel (ARC) receiver.
The device is offered in a 144‑lead, 20 mm × 20 mm Pb‑free LQFP package.
