The OP‑15, OP‑16 and OP‑17 are precision JFET‑input operational amplifiers from Analog Devices. They combine low input offset voltage (as low as 0.5 mV) with high speed performance, offering slew rates from 13 V/µs (OP‑15) up to 60 V/µs (OP‑17) and gain‑bandwidth products up to 5 MHz.
These devices are available in several surface‑mount and through‑hole packages, including TO‑96, 8‑Pin DIP, 8‑Pin Harmonic DIP and 6‑Pin SO. They feature low input bias currents (9 nA at 125 °C for OP‑15) and are offered with MIL‑STD‑883 processing for military applications.
| Input Offset Voltage (typical) | 0.5 mV |
|---|---|
| Slew Rate (OP‑15) | 13 V/µs |
| Slew Rate (OP‑16) | 25 V/µs |
| Slew Rate (OP‑17) | 60 V/µs |
| Gain‑Bandwidth Product (OP‑17) | 5 MHz |
| Input Bias Current (OP‑15, 125 °C) | 9 nA |
The OP‑15 typically has an input offset voltage of 0.5 mV.
The OP‑16 has a typical slew rate of 25 V/µs.
Yes, models with MIL‑STD‑883 processing are available; part numbers include the “‑883” suffix.
