This document is AD5764's detailed information. AD5764 is a 16-bit high-precision, serial input, bipolar voltage output DAC produced by Analog Devices. AD5764 has a ±10 V, ±10.2564 V or ±10.5263 V output range, ±1 LSB maximum INL error and ±1 LSB maximum DNL error. AD5764 also has low noise, 10 μs maximum settling time, integrated reference buffers, output control circuitry, programmable short-circuit protection, LDAC simultaneous update, asynchronous CLR clear code, digital offset and gain adjustment, logic output control pins, etc. AD5764 is suitable for industrial automation, open-loop/closed-loop servo control, process control, data acquisition systems, automatic test equipment, automotive test and measurement, etc.
The AD5764 is a high‑accuracy, 16‑bit, quad digital‑to‑analog converter that accepts serial input and provides bipolar voltage outputs. It features programmable output ranges (±10 V, ±10.2564 V, or ±10.5263 V), integrated reference buffers, short‑circuit protection, and simultaneous updating via LDAC. The device operates from ±11.4 V to ±16.5 V and is rated for an industrial temperature range of –40 °C to +85 °C.
Typical applications include industrial automation, servo control, data‑acquisition systems, automatic test equipment, and high‑accuracy instrumentation. The datasheet includes functional block diagrams, timing specifications, absolute maximum ratings, pin descriptions, layout guidelines, and recommended precision voltage references.
| Maximum Settling Time | 10 µs |
|---|---|
| INL (Integral Non‑Linearity) | ±1 LSB max |
| DNL (Differential Non‑Linearity) | ±1 LSB max |
| Supply Voltage | ±11.4 V to ±16.5 V |
| Operating Temperature Range | –40 °C to +85 °C |
The AD5764 settles to its final output within 10 µs maximum.
It operates from ±11.4 V to ±16.5 V on the analog supplies.
The output can be programmed to ±10 V, ±10.2564 V, or ±10.5263 V.
