This is a 32-button voice telephone console that can be connected to the SPA962 IP phone, providing 32 programmable speed-dial or direct station select (DSS) buttons.
The SPA932 Attendant Console adds 32 programmable multi‑color LED buttons to a Linksys SPA962 IP phone, allowing quick call handling, speed‑dial, and line‑status monitoring from a central location. It is designed for small businesses that need an affordable way to expand their voice network.
Installation is simple: attach the supplied bracket and cable to the SPA962 phone, which also powers the console, so no extra power source is required. The modular design supports up to two consoles for a total of 64 buttons, and the unit complies with SIP standards for broad interoperability.
| Model | SPA932 |
|---|---|
| Ports | 2 Auxiliary Ports |
| Buttons | 32 programmable multi‑color LED buttons |
| LED Colors | Green, Red, Orange |
| Dimensions | 4 x 8.5 x 1.5 in (102 x 216 x 38 mm) |
| Weight | 2 lbs (0.9 kg) |
| Operating Temperature | 41 to 113°F (5 to 45°C) |
| Storage Temperature | -13 to 185°F (-25 to 85°C) |
| Operating Humidity | 10 to 90% non‑condensing |
| Certification | FCC, cUL, CE, Canadian ICES‑003 |
The SPA932 requires a Linksys SPA962 IP phone as the minimum requirement.
It provides 32 programmable multi‑color LED buttons.
No, it draws power from the attached SPA962 phone and does not need an additional power source.
Green indicates idle, red indicates in‑use, blinking red indicates ringing, and orange indicates a registration error.
