The document describes the features and characteristics of the Wireless-N PCI Adapter Model: WMP300N (EU) wireless card, including fast connection speeds and wide coverage provided by Wireless-N technology, compatibility with Wireless-G and -B networks, easy installation and configuration, and strong security protection.
The Linksys WMP300N (EU) is a Wireless‑N PCI adapter designed for desktop computers, offering high‑speed Wi‑Fi connectivity with support for 802.11b/g/n standards. It includes MIMO technology for extended range and supports WPA2 encryption for secure networking.
This manual covers the step‑by‑step installation wizard, hardware specifications, package contents, and regulatory information. It also lists system requirements and provides guidance on configuring the adapter for optimal performance.
| Standards | IEEE 802.11b, IEEE 802.11g, Draft IEEE 802.11n, PCI 2.3 |
|---|---|
| Channels (Europe) | 13 |
| Transmitted Power | 12±1 dBm (802.11g), 10±1 dBm (Wireless‑N) |
| Receive Sensitivity | 54 Mbps @ -70 dBm (Typical); Wireless‑N @ -70 dBm (Typical) |
| Security Features | WEP, WPA, WPA2 |
| Dimensions | 133 × 22 × 121 mm |
| Weight | 62 g |
| Operating Temperature | 0 °C to 50 °C |
| Operating Humidity | 10 % to 80 % non‑condensing |
The adapter works with Windows 2000, Windows XP with Service Pack 1, and later Windows versions.
It supports WEP, WPA, and WPA2 encryption, including Wi‑Fi Protected Access™ (WPA2) with up to 256‑bit encryption.
The adapter measures 133 × 22 × 121 mm and weighs 62 g.
