The IRS2336(D) IRS23364D is a high voltage three-phase gate driver IC from International Rectifier. The main feature is that it supports six IGBT/MOSFET power devices, and can drive 20V voltage. It has over-current protection, over-temperature shutdown input, advanced input filter, integrated dead time protection, shoot-through (cross-conduction) protection, under-voltage lockout for VCC and VBS, enable/disable input and fault reporting, adjustable fault clear timing, separate logic and power grounds, 3.3V input logic compatible, tolerance to negative transient voltage, designed for use with bootstrap power supplies, matched propagation delays for all channels, -40°C to 125°C operating range, RoHS compliant, and lead-free.
The IRS2336x(D) family are high‑voltage, high‑speed gate‑driver ICs with three high‑side and three low‑side channels for 3‑phase applications. They integrate bootstrap functionality, over‑current, over‑temperature, and undervoltage protection, and support 3.3 V logic inputs.
Typical applications include appliance motor drives, servo drives, micro‑inverter drives, and general‑purpose three‑phase inverters. The devices are offered in multiple packages such as 28‑lead PDIP, SOIC, 48‑lead MLPQ, and 44‑lead PLCC, with both tube/bulk and tape‑and‑reel options.
| Number of channels | 6 (three high‑side, three low‑side) |
|---|---|
| Gate‑drive supply voltage per channel | up to 20 V |
| Operating temperature range | -40 °C to 125 °C |
| Input logic voltage compatibility | 3.3 V logic compatible |
| Maximum device voltage rating | 600 V |
The devices operate from –40 °C to 125 °C.
It provides six output channels – three high‑side and three low‑side.
Typical applications include appliance motor drives, servo drives, micro‑inverter drives, and general‑purpose three‑phase inverters.
Packages include 28‑lead PDIP, 28‑lead SOIC wide body, 48‑lead MLPQ7×7, and 44‑lead PLCC, with both tube/bulk and tape‑and‑reel forms.
