This is a user guide for Linksys WRT160N wireless broadband router
This guide introduces the Linksys WRT160N Wireless‑N Broadband Router, describing its front and back panels, LEDs, ports, and basic functions such as internet connectivity, wireless operation, and power management. It also explains the Wi‑Fi Protected Setup button and LED indicators for status monitoring.
The manual covers detailed configuration steps, including the wireless security checklist, basic and advanced setup via the web‑based utility, DHCP server settings, IP configuration, and optional features like MAC filtering, VPN passthrough, and QoS. Appendices provide troubleshooting tips, full specifications, warranty details, and regulatory information.
| Standards | 802.11n, 802.11g, 802.11b, 802.3, 802.3u |
|---|---|
| Ports | Power, Internet, and Ethernet |
| Buttons | Reset, Wi‑Fi Protected Setup |
| LEDs | Ethernet (1‑4), Wi‑Fi Protected Setup, Wireless, Internet, Power |
| Cabling Type | CAT 5e |
| RF Power (EIRP) | 17 dBm |
| Antenna Gain | 1.5 dBi |
| Security Features | WEP, WPA, WPA2 |
| Security Key Bits | 128‑Bit, 256‑Bit |
| Dimensions | 7.95" x 6.3" x 1.34" (202 x 160 x 34 mm) |
| Weight | 13.40 oz (0.38 kg) |
| Power | 12V, 1A |
| Operating Temperature | 0 to 40°C (32 to 104°F) |
| Storage Temperature | -20 to 60°C (-4 to 140°F) |
| Operating Humidity | 10 to 85% Noncondensing |
| Storage Humidity | 5 to 90% Noncondensing |
Press and hold the Reset button for about five seconds, or use the Administration > Factory Defaults option in the web utility.
Enter 192.168.1.1 in a web browser to reach the router’s configuration page.
